The Pit Parking System is a kind of self parking with PLC controled, we can make it from 2-4 floor. When parking or pick car, you just need to read your IC Card or input the code, the car will come to the groung floor to your front. It is hydraulic drive mode and its speed can up to 8m/min. It is very convenient and time saving.
Pit parking lift, 3 layers pit parking lift, 3 levels pit parking lift
Description
PP301 is a kind of self parking equipment with simple structure, it moves vertically in the pit so people could park or retrieve any vehicle easily without moving other vehicle out first. It can make full use of limited land with convenient parking & retrieve. It's the motor drive system, fitting for separate unit or small quantity.
Technical Parameter
| MODEL NO. | PP301(-2+1 pit car parking lift) |
| Lifting Capacity: | 2500kgs; |
| Lifting Height: | 1800mm/70.90" |
| Total Length: | 5340mm; |
| Platform Width: | 2000mm; |
| Total Width: | 2850mm; |
| Lock Mode+ Control Mode: | Manual Release+ 24V Electric Control |
| Motor: | 5.5KW; |
| Warranty: | 24 months; |
| Surface treatment: | Powder coated; |
| Application | Three parking places, Can park:Big SUV on top 2 floors & Compact SUV on ground; |
| Loading quantity | 4 sets/20ft; 8 sets/40ft; |
Benefit
Simple operation
Safe and reliable
Convenient in and out of car
Ultra low noise
Small space occupation
Beautiful and fashionable in appearance
Easy and fast installation
Both suitable for home use and public use
Product Show & Installation
