The newest and most innovative double deck underground vehicle parking system. This is a dream for auto aficionados who like to maintain a hands-on relationship with their machines. Double deck vehicle parking system heavy-duty scissors style lift Designed to lift up to two 7,000 lb. Vehicles simultaneously.
The deck structure and components are completely concealed below ground so there is no indication that a lift (or second car) is present when lowered. The Double deck car platform, a unique breed of lift for the uncompromising property owners that need affordable parking space.This 2-deck drive-on lift is a smart solution for both commercial and residential applications.
Technical Parameter
|
MODEL NO. |
SPP201-2500 |
|
Lifting Capacity: |
2500kgs; |
|
Lifting Height: |
2500mm/1750mm |
|
Total Length: |
5400mm; |
|
Platform Width: |
2450mm; |
|
Total Width: |
2600mm; |
| Lock Mode+ Control Mode: |
Manual Release+ 24V Electric Control |
|
Motor: |
5.5KW; |
|
Warranty: |
24 months; |
|
Surface treatment: |
Powder coated; |
| Application |
Three parking places, Can park:Big SUV on top 2 floors & Compact SUV on ground; |
| Loading quantity |
4 sets/20ft; 8 sets/40ft; |
1) Adopt high tensile Mn rectangular steel tube
2) Hydraulic system can ensure the smooth operation and little maintenance
3) Convenient push button on each stops
4) Equipped with protection safety device to prevent the car lift from falling down and overload, can guarantee the operation safety
5) Equipped with explosion-proof valves: protect hydraulic pipe, anti-hydraulic pipe rupture
6) Spillover valve: It can prevent high pressure when the machine moves up. Adjust the pressure
7) Has emergency stop value if power failures
8) Custom-made according to different site requirement, including lifting height, load capacity, platform size, working alarm, etc.
9) Easy installation and easy operation
10）No emission and low noise, environment friendly
Product Show & Installation
